Feeding sizes: ≤30mm
Production capacity: 0.5-120 t/h
Applicable materials: Dolomite, limestone, potash feldspar, calcite, barite, talc, diabase, quartz, bentonite, gypsum, etc.
Applications: Calcium carbonate grinding process,Gypsum powder processing, Power plant desulfurization, Non-metallic mineral powder Processing, Preparation of pulverized coal
Zhongde Heavy Industries Co., Ltd. China(Mainland)
R-type Raymond Mill finished grain size can be processed into 80-325 mesh range of arbitrary, part of the material up to 600 head.
Advantage of Raymond Mill:
1. Raymond Mill is designed with a distinctive structure, so that the space occupied by smaller,
transportation, installation, operation and maintenance more convenient. And the use of PLC electrical automation control, effectively reduces the equipment failure rate, labor costs, achieving high production and efficient production. It also achieves zero noise, zero pollution, a good production environment,
2. Raymond Mill grinding powder fineness can be adjusted between 80-800 mesh.The applicability is more flexible and extensive.Overall, Raymond Mill is the best choice for non-metallic mineral milling.
| Parameter Model |
Raymond mill62 | High strength66 | High strength76 | High strength87 | High strength92 | High strength93 | High strength97 | Raymond mill4119 | Raymond mill4525 |
| Feeding size（mm） |
<15 | <15 | <20 | <25 | <25 | <25 | <25 | ≤25 | ≤30 |
| Size of finished product（mm） |
0.173-0.033 | 0.173-0.033 | 0.173-0.033 | 0.173-0.033 | 0.173-0.033 | 0.173-0.033 | 0.173-0.033 | 0.173-0.044 | 0.173-0.044 |
| Shift output of different material fineness(t) |
0.6-9 | 1-20 | 1.5-25 | 2.8-33 | 3-36 | 3.5-40 | 4-52 | 8-78 | 16-176 |
| Rotate speed of central shart（r/min） |
274 | 190 | 170 | 161 | 148 | 140 | 130 | 105 | 82 |
| Diameter of pulverizing ring（mm） |
525 | 725 | 850 | 907.5 | 973 | 1006 | 1050 | 1400 | 1770 |
| Diameter of pulverizing ring（mm） |
150 | 210 | 250 | 270 | 300 | 300 | 310 | 410 | 450 |
| Height of pulverizing roller（mm） |
100 | 150 | 150 | 150 | 160 | 160 | 170 | 190 | 250 |
| Main Motor(kw) | 7.5 | 15 | 18.5 | 22 | 30 | 30 | 37 | 75 | 132 |
| Fan Motor | 4-5.5 | 4-11 | 4-15 | 4-18.5 | 4-22 | 2-22 | 4-37 | 4-75 | 4-132 |
| Analyzer Motor | 6-1.1 | 6-2.2 | 6-2.2 | 6-2.2 | 6-2.2 | 6-3 | 4A-5.5 | 4B-7.5 | 4A-18.5 |
